Breeding Profile Series Roll Forming Machine and production line

The Breeding Profile Series Roll Forming Machine of breeding equipment profile series is a highly automated production line integrating decoiler, shearing butt welding, leveler, servo feeding, punching, roll forming, straightening, cutting, and palletizing.
A Breeding Profile Series Roll Forming production line can produce 12 different types of plate types. By adjusting the position of the guide wheel, the width of the servo, and the gap between the rollers, and changing the punching die, platen assembly, and cutting die, the rapid replacement of different product types can be realized.
The profile produced by this production line has good mechanical properties such as compression resistance and bending resistance, and is widely used in animal husbandry.

ITEM		PARAMETER
Raw material specifications	Steel Type	Galvanized steel coil
	Strength(MPa)	<=235(MPa)
	Thickness	0.8(mm)
	Coil inner diameter	508(mm)
	Weight	3(T)
Sheet Width		300(mm)
Production Line Speed		12(m/min)
Roller Material		Chrome 12
Roller Driving Mode		External transmission
Operational Program		Windows2000
Total Motor Power		85KW
Control System		PLC automatic control system
